H12-351_V1.0 Practice Exam Questions and Answers

According to the Huawei documents and resources, the encapsulation formats used for EAP termination in 802.1X authentication are as follows:

• B.

   EAPoL: The client and access device exchange information using EAPoL packets across the LAN2.

• C.

   EAPoR: The access device directly encapsulates the received EAP packets into RADIUS using EAP over RADIUS (EAPoR) packets2.

Therefore, B and C are the correct answers. References: 2: https://support.huawei.com/enterprise/en/doc/EDOC1100086527

According to the Huawei documents and resources, the features and application scenarios of the wireless positioning solutions are as follows:

• Wi-Fi terminal positioning: Performs network-side positioning generally based on the RSSI, but provides low positioning accuracy. This method applies to scenarios such as precision marketing and customer flow analysis in shopping malls.
• Bluetooth tag positioning: Runs based on the built-in Bluetooth module of an AP. The AP reports data to a positioning engine for location resolution. This positioning technology provides low positioning accuracy and applies to asset positioning and personnel positioning scenarios.
• UWB positioning: Provides high positioning accuracy, and is applicable to scenarios that require high accuracy, such as intelligent manufacturing, warehousing logistics, and mechanical manufacturing.
• Bluetooth terminal positioning: Runs based on the built-in Bluetooth module of an AP, which can be implemented on either the network side or terminal side.

Therefore, Wi-Fi terminal positioning - 3, Bluetooth tag positioning - 4, UWB positioning - 2, Bluetooth terminal positioning - 1 is the correct answer. References: : https://support.huawei.com/enterprise/en/doc/EDOC1100158948/9a0d5c37/wi-fi-terminal-positioning : https://support.huawei.com/enterprise/en/doc/EDOC1100158948/9a0d5c37/bluetooth-tag-positioning : https://support.huawei.com/enterprise/en/doc/EDOC1100158948/9a0d5c37/uwb-positioning : https://support.huawei.com/enterprise/en/doc/EDOC1100158948/9a0d5c37/bluetooth-terminal-positioning

C is false because HTTPS redirection is not required for Portal authentication to work properly.

References: https://support.huawei.com/enterprise/en/doc/EDOC1100058940/8a8f1c9b/troubleshooting-portal-authentication-failures

Huawei APs can identify non-Wi-Fi devices that operate in the 2.4 GHz frequency band, such as Bluetooth devices, ZigBee devices, game controllers, wireless video and audio transmitters, microwave ovens, cordless phones, and baby monitors.

References: https://support.huawei.com/enterprise/en/doc/EDOC1100058940/8a8f1c9b/non-wi-fi-device-identification

The display sync-configuration compare command is used to check whether the public configurations on two WACs are consistent after wireless configuration synchronization. The command output shows the differences between the configurations on the master and backup WACs. In this case, the configuration of vap-profile name 3 exists on the master WAC but not on the backup WA

C.

References: https://support.huawei.com/enterprise/en/doc/EDOC1100058940/8a8f1c9b/display-sync-configuration-compare
